MSI

Placa base MSI Pro H610M-G LGA1700 DDR4

Placas base● In Stock
$108.00
Qty
Flexible Payment Options
4 interest-free payments of $27.00 — Learn more
As low as $9.00/mo — Learn more
Lease-to-own from $2.07/wk — no credit needed. Apply at checkout
Finance from $4.50/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
Overview
ModelMSI PRO H610M-G DDR4
SeriesPRO Series
Form FactorMicro-ATX (mATX)
OS SupportWindows 11 64-bit, Windows 10 64-bit
Processor
CPU SocketLGA 1700
Supported CPUsIntel Core 14th / 13th / 12th Gen, Pentium Gold, Celeron (LGA 1700)
ChipsetIntel H610
Chipset CoolingPassive Heatsink
CPU TDP Support75W
Power Design8+1+1 Phase (Core Boost)
Memory
Memory TypeDDR4
Memory Slots2x DIMM (UDIMM)
Max Memory64 GB
Supported Speeds2133 / 2400 / 2666 / 2800 / 2933 / 3000 / 3200 MHz (Max 3200 by JEDEC & POR)
ChannelDual Channel
Memory StandardNon-ECC, Unbuffered
XMP SupportYes (MSI OC LAB Tested XMP Profiles)
Expansion Slots
PCIe x16 Slot1x PCIe 4.0 x16 (from CPU) — Steel Armor reinforced
PCIe x1 Slot1x PCIe 3.0 x1
M.2 Slot (Storage)1x M.2 (Turbo Gen3, up to 32 Gb/s)
M.2 Slot (Wi-Fi)1x M.2 E-Key (PCIe Wi-Fi module only)
Storage
SATA III Ports4x SATA III (6 Gb/s)
Display Output (Integrated Graphics)
HDMI1x HDMI 2.1 with HDR — up to 4K @ 60Hz
DisplayPort1x DisplayPort 1.4 — up to 4K @ 60Hz
VGA1x VGA (D-Sub) — up to 2048×1536 @ 50Hz / 1920×1200 @ 60Hz
USB
USB 3.2 Gen 1 (Rear)2x USB 3.2 Gen 1 Type-A (5 Gb/s)
USB 3.2 Gen 1 (Front Header)2x USB 3.2 Gen 1 (internal connector)
USB 2.0 (Rear)4x USB 2.0 Type-A (via hub GL850G)
USB 2.0 (Front Header)2x USB 2.0 (internal connector)
Networking
LAN ControllerIntel I219V
LAN Speed1 Gbps
Wi-FiNone (M.2 E-Key slot for optional Wi-Fi module)
Audio
Audio CodecRealtek ALC892 / ALC897
Channels7.1-Channel HD Audio (Audio Boost)
Rear Audio Jacks3x 3.5mm Stereo Jacks
Front Audio Header1x HD Audio Front Panel Header
Rear I/O Panel
PS/21x PS/2 (MiniDIN-6)
LAN1x RJ-45
USB 3.2 Gen 1 Type-A2x
USB 2.0 Type-A4x
Video Outputs1x HDMI 2.1, 1x DisplayPort 1.4, 1x VGA
Audio Jacks3x 3.5mm
Internal Connectors
ATX Power1x 24-Pin ATX
CPU Power1x 8-Pin (12V ATX)
SATA III4x
USB 3.2 Gen 1 Header1x (supports 2x USB 3.2 Gen 1)
USB 2.0 Header1x (supports 2x USB 2.0)
Front Panel Audio Header1x HD Audio
RGB Header (12V)1x 4-Pin LED RGB
ARGB Header (5V)2x 3-Pin Addressable LED (ARGB)
CPU Fan Header1x 4-Pin (PWM)
System Fan Header1x 4-Pin SYS_FAN
TPM Header1x
Chassis Intrusion1x
BIOS
BIOS InterfaceMSI Click BIOS 5
BIOS NotesBIOS update may be required for 13th / 14th Gen Intel CPU support
Features & Technology
Core BoostPremium digital power layout for stable CPU power delivery
Memory BoostFully isolated DDR circuit for pure memory signal integrity
Lightning Gen4PCIe 4.0 solution — up to 64 GB/s bandwidth
Steel ArmorReinforced PCIe x16 slot with extra solder points and EMI shielding
Frozr AI CoolingAuto fan adjustment based on CPU & GPU temperatures
Audio BoostIsolated audio PCB layer with dedicated HD audio processor
The MSI Pro H610M-G Motherboard (DDR4) (LGA1700) (TDP 75W) (M-ATX) is a Common-tier custom gaming PC built and tested by TieredUp Tech in Orange, TX. This machine delivers 100+ FPS in esports titles like Fortnite, Valorant, and Apex Legends at 1080p ultra settings — making it the perfect entry point into PC gaming. This build is optimized for Fortnite, Valorant, Apex Legends, Minecraft, League of Legends, and CS2. Whether you are jumping into your first PC gaming experience or upgrading from an older system, the MSI Pro H610M-G Motherboard (DDR4) (LGA1700) (TDP 75W) (M-ATX) delivers exceptional performance straight out of the box. Every Common-tier BitCrate gaming PC is hand-assembled, stress-tested, and quality checked by our technicians before shipping. We stand behind every build with a 30-day warranty and ongoing technical support from our team in Orange, TX. Priced at $110.40 and in stock now, the MSI Pro H610M-G Motherboard (DDR4) (LGA1700) (TDP 75W) (M-ATX) represents outstanding value for its performance tier. Order today and experience the TieredUp Tech difference — premium gaming performance at every price point. Specifications at a glance: • Build Tier: Common • Built & tested in Orange, TX • 30-day warranty included • Free shipping on orders over $1,200
Related Products
GeekTech GryphiX B450M-A AMD AM4 Socket Motherboard M-ATX Micro ATX (DDR4) (AMD) (AM4) (TDP 125W) (M-ATX)
GeekTech GryphiX B450M-A AMD AM4 Socket Motherboard M-ATX Micro ATX (DDR4) (AMD) (AM4) (TDP 125W) (M-ATX)
$68.77
Placa base ASRock B760M-HDV/M.2 DDR5
Placa base ASRock B760M-HDV/M.2 DDR5
$167.98
ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX)
ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX)
$151.31
H61 LGA 2nd 3rd Generation i3 i5 i7 Pentium Celeron DDR3 HDMI VGA Motherboard(LGA1155) (Intel)
H61 LGA 2nd 3rd Generation i3 i5 i7 Pentium Celeron DDR3 HDMI VGA Motherboard(LGA1155) (Intel)
$26.92
ASUS TUF Gaming Z790-PLUS WiFi 6E (DDR5) (Intel) (LGA1700) (TDP 170W) (M-ATX)
