ASUS TUF Gaming Z790-PLUS WiFi 6E (DDR5) (Intel) (LGA1700) (TDP 170W) (M-ATX)

Motherboard● In Stock
$242.34
Qty
Flexible Payment Options
4 interest-free payments of $60.58 — Learn more
As low as $20.19/mo — Learn more
Lease-to-own from $4.66/wk — no credit needed. Apply at checkout
Finance from $10.09/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
Overview
ModelTUF GAMING Z790-PLUS WIFI (DDR5)
Form FactorATX
ChipsetIntel® Z790
CPU SocketIntel® LGA 1700
Supported CPUsIntel® Core™ 14th, 13th & 12th Gen; Pentium® Gold; Celeron®
Turbo BoostIntel® Turbo Boost Technology 2.0 & Turbo Boost Max Technology 3.0
Power Delivery
VRM Topology16+1 DrMOS Power Stages
Current Rating per Stage60A per stage (CPU: 16×60A + SoC: 1×60A)
PCB LayersSix-layer PCB
ATX Power Connector1× 24-pin Main Power
CPU Power Connectors2× 8-pin +12V (ProCool)
Memory
DIMM Slots4× DIMM
Memory TypeDDR5, Non-ECC, Unbuffered
Max Capacity192 GB
Supported SpeedsDDR5-4800 / 5000 / 5200 / 5400 / 5600 / 5800(OC) / 6000(OC) / 6200(OC) / 6400(OC) / 6600(OC) / 6800(OC) / 7000(OC) / 7200(OC)
Memory ArchitectureDual Channel
OC ProfilesIntel® XMP, ASUS OptiMem II, ASUS AEMP II
Expansion Slots
PCIe 5.0 x161× (CPU lanes) — SafeSlot reinforced
PCIe 4.0 x16 (x4 mode)1× (Z790 chipset, max x4 electrical)
PCIe 4.0 x41× (Z790 chipset)
PCIe 3.0 x12×
Storage
M.2 Slots (Total)4× M.2 (Key-M)
M.2_1 (CPU)Type 2242/2260/2280/22110 — PCIe 4.0 x4 (13th/12th Gen)
M.2_2 (Chipset)Type 2242/2260/2280 — PCIe 4.0 x4
M.2_3 (Chipset)Type 2242/2260/2280/22110 — PCIe 4.0 x4
M.2_4 (Chipset)Type 2242/2260/2280 — PCIe 4.0 x4 & SATA
SATA Ports4× SATA 6Gb/s
RAID SupportIntel® RST: PCIe RAID 0/1/5/10; SATA RAID 0/1/5/10
Rear I/O — USB
USB 3.2 Gen 2×2 (20Gbps)1× Type-C®
USB 3.2 Gen 2 (10Gbps)3× (2× Type-A + 1× Type-C®)
USB 3.2 Gen 1 (5Gbps)4× Type-A
Total Rear USB Ports8
Internal USB Headers
USB 3.2 Gen 2 (10Gbps)1× connector (supports Type-C®)
USB 3.2 Gen 1 (5Gbps)1× header (adds 2 ports)
USB 2.0 Headers2× headers (adds 4 ports)
Total Front USB Ports7
Networking
Ethernet ControllerIntel® 2.5 Gigabit Ethernet
LAN ProtectionTUF LANGuard (surge & ESD protection)
Wi-Fi StandardWi-Fi 6E — 802.11 a/b/g/n/ac/ax (2×2)
Wi-Fi Frequency Bands2.4 GHz / 5 GHz / 6 GHz
BluetoothBluetooth® 5.3
Wi-Fi AntennaASUS Wi-Fi moving antenna (4-way positioning, magnetic base)
Video Output (iGPU)
DisplayPort1× DisplayPort 1.4 (max 4K@60Hz)
HDMI1× HDMI® 2.1 (max 4K@60Hz)
Audio
Audio CodecRealtek S1220A — 7.1 Surround Sound HD Audio
SNR (Playback)120 dB
SNR (Recording)113 dB (Line-in)
Max Playback Resolution32-bit / 192 kHz
Rear Audio Jacks5× 3.5mm (Mic, Line-In, Rear Speaker, Subwoofer, Line-Out)
Digital AudioRear Optical S/PDIF output
Audio FeaturesAudio Shielding, Dedicated Audio PCB Layers, Premium Audio Capacitors, Audio Cover, DTS Audio Processing, Two-Way AI Noise Cancelation
Front Panel Header1× AAFP (Front Panel Audio Header)
Fan & Cooling Headers
CPU Fan Header1× 4-pin
CPU OPT Fan Header1× 4-pin
AIO Pump Header1× 4-pin
Chassis Fan Headers4× 4-pin (auto-detect PWM/DC)
Cooling SoftwareFan Xpert 4 with AI Cooling II
HeatsinksEnlarged VRM heatsink, PCH heatsink, M.2 heatsinks (×3 slots)
Miscellaneous Internal Headers
Addressable Gen 2 (ARGB)3× headers
Aura RGB Header1×
Clear CMOS Header1×
COM Port Header1×
System Panel Header1× 20-3 pin (with chassis intrusion)
Thunderbolt™ (USB4®) Header1× (supports ASUS ThunderboltEX 4 card — up to 40 Gbps)
Protection & Q-Design Features
TUF ProtectionDIGI+ VRM, ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot, Stainless-Steel Back I/O
Q-DesignM.2 Q-Latch, PCIe Slot Q-Release, Q-DIMM, Q-Slot, Q-LED (CPU/DRAM/VGA/Boot)
EZ DIYCPU Socket Lever Protector, ProCool Connectors, Pre-mounted I/O Shield, SafeDIMM
Q-LED IndicatorsCPU (red), DRAM (yellow), VGA (white), Boot Device (yellow-green)
Lighting
Onboard LightingEdge lighting design (Aura Sync RGB)
ARGB Headers3× Addressable Gen 2
RGB Strip Header1× Aura RGB header
Sync EcosystemAura Sync (via Armoury Crate / Aura Creator)
Software & BIOS
ASUS Exclusive SoftwareArmoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, AI Cooling II, Two-Way AI Noise Cancelation, Power Saving)
AI Suite 3TurboV EVO, DIGI+ VRM, PC Cleaner
Third-Party BundledTUF GAMING CPU-Z, DTS Audio Processing, MyASUS, Norton 360 (60-day trial), WinRAR (40-day trial)
BIOSASUS UEFI BIOS EZ Mode, AI Overclocking Guide
BIOS UtilitiesASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS MyHotkey
In the Box
Cables2× SATA 6Gb/s cables
Miscellaneous1× ASUS Wi-Fi moving antenna, 1× TUF GAMING sticker, 2× M.2 rubber packages, 1× M.2 screw package
Documentation1× TUF Certification card, 1× User guide (Quick start guide)
The ASUS TUF Gaming Z790-PLUS WiFi 6E (DDR5) (Intel) (LGA1700) (TDP 170W) (M-ATX) is a Common-tier custom gaming PC built and tested by TieredUp Tech in Orange, TX. This machine delivers 100+ FPS in esports titles like Fortnite, Valorant, and Apex Legends at 1080p ultra settings — making it the perfect entry point into PC gaming. This build is optimized for Fortnite, Valorant, Apex Legends, Minecraft, League of Legends, and CS2. Whether you are jumping into your first PC gaming experience or upgrading from an older system, the ASUS TUF Gaming Z790-PLUS WiFi 6E (DDR5) (Intel) (LGA1700) (TDP 170W) (M-ATX) delivers exceptional performance straight out of the box. Every Common-tier BitCrate gaming PC is hand-assembled, stress-tested, and quality checked by our technicians before shipping. We stand behind every build with a 30-day warranty and ongoing technical support from our team in Orange, TX. Priced at $242.34 and in stock now, the ASUS TUF Gaming Z790-PLUS WiFi 6E (DDR5) (Intel) (LGA1700) (TDP 170W) (M-ATX) represents outstanding value for its performance tier. Order today and experience the TieredUp Tech difference — premium gaming performance at every price point. Specifications at a glance: • Build Tier: Common • Built & tested in Orange, TX • 30-day warranty included • Free shipping on orders over $1,200
