| General | |
|---|---|
| Brand | NZXT |
| Model Number | CC-H61FW-01 |
| UPC | 810074844130 |
| EAN | 5056547204048 |
| Product Line | H6 Flow |
| Form Factor | ATX Mid-Tower |
| Color | White |
| Design Type | Compact Dual-Chamber Airflow |
| Dimensions & Weight | |
| Height (with Feet) | 435 mm (17.13 in) |
| Width | 287 mm (11.3 in) |
| Depth | 415 mm (16.34 in) |
| Volume | 51.8 L (1.83 ft³) |
| Weight | 9.4 kg |
| Materials | |
| Frame Material | Galvanized Cold Rolled Steel (SGCC) |
| Side Panel Material | Ultra-Clear Tempered Glass |
| Window Panels | Panoramic — Left Side & Front |
| Motherboard & Compatibility | |
| Supported Motherboard Form Factors | ATX, Micro-ATX, Mini-ITX |
| Max GPU Length | 365 mm (14.37 in) |
| Max CPU Cooler Height | 163 mm (6.42 in) |
| Max PSU Length | 200 mm (7.87 in) |
| PSU Form Factor Support | ATX, SFX |
| Vertical GPU Mount | Supported (mount sold separately) |
| Expansion & Storage | |
| Expansion Slots | 7 × Full-Height |
| Internal 3.5" Drive Bays | 1 |
| Internal 2.5" Drive Bays | 2 |
| Cooling — Fans | |
| Pre-Installed Fans | 3 × 120mm (angled front-right corner) |
| Total Fan Slots | 9 |
| Front Fan Support | 3 × 120mm |
| Top Fan Support | 2 × 140mm or 3 × 120mm |
| Bottom Fan Support | 2 × 140mm |
| Rear Fan Support | 1 × 120mm |
| Cooling — Radiator Support | |
| Top Radiator Support | Up to 360mm (240mm / 280mm / 360mm) |
| Front Radiator Support | Up to 360mm (240mm / 360mm) |
| Rear Radiator Support | 120mm |
| Front I/O Ports | |
| USB-A Ports | 2 × USB 3.2 Gen 1 Type-A |
| USB-C Port | 1 × USB 3.2 Gen 2x2 Type-C |
| Audio | 1 × 3.5mm Combo Headphone / Mic Jack |
| Buttons | Power, Reset |
| Dust Filtration | |
| Dust Filter Locations | Top, Front (removable) |
| Cable Management | |
| Cable Management Features | Wide channels with included cable straps |
| Chamber Design | Dual-Chamber (PSU & storage hidden behind motherboard tray) |
| Panel Access | |
| Tool-Free Panel Access | Yes — Top and Side panels |
| Panel Perforation | Airflow-optimized perforation on top and side panels |
| RGB Controller Included | No |
The NZXT H6 Flow is a white ATX gaming case designed around airflow, shipping with three 120mm fans mounted on the side panel. It supports standard ATX motherboards and ATX power supplies, with room for graphics cards up to 365mm long and CPU coolers up to 163mm tall.
The case offers flexible cooling options: top radiator support up to 360mm, side and bottom fan mounts, and front I/O that includes two USB 3.2 Gen 1 Type-A ports plus one USB 3.2 Gen 2x2 Type-C port. For builders planning a clean white gaming setup with space for serious hardware, the H6 Flow provides the structure and ventilation to get started.
