AMD Ryzen 7 9800X3D 4.7Ghz (8-Core, 16 Threads, 104MB Cache) CPU w/ Radeon Graphics (RDNA 2) (TDP 165W) (AM5) CLICK TO EXPAND
AMD Ryzen 7 9800X3D 4.7Ghz (8-Core, 16 Threads, 104MB Cache) CPU w/ Radeon Graphics (RDNA 2) (TDP 165W) (AM5)
AMD Ryzen 7 9800X3D 4.7Ghz (8-Core, 16 Threads, 104MB Cache) CPU w/ Radeon Graphics (RDNA 2) (TDP 165W) (AM5)
AMD Ryzen 7 9800X3D 4.7Ghz (8-Core, 16 Threads, 104MB Cache) CPU w/ Radeon Graphics (RDNA 2) (TDP 165W) (AM5)
TieredUp Tech, Inc.

AMD Ryzen 7 9800X3D 4.7Ghz (8-Core, 16 Threads, 104MB Cache) CPU w/ Radeon Graphics (RDNA 2) (TDP 165W) (AM5)

Processors● In Stock
$591.52
Qty
Flexible Payment Options
4 interest-free payments of $147.88 — Learn more
As low as $49.29/mo — Learn more
Lease-to-own from $11.37/wk — no credit needed. Apply at checkout
Finance from $24.64/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
General Information
BrandAMD
ModelAMD Ryzen™ 7 9800X3D
Family / SeriesRyzen 9000 Series
CodenameGranite Ridge
Form FactorDesktop, Boxed (No Cooler Included)
Product ID (Boxed)100-100001084WOF
Product ID (Tray)100-000001084
Core Architecture
MicroarchitectureZen 5
CPU Die Process (CCD)TSMC 4nm FinFET
I/O Die Process (IOD)TSMC 6nm FinFET
CPU Cores8
Threads16
Simultaneous Multithreading (SMT)Yes
CPU SteppingC0
Clock Speeds
Base Clock4.7 GHz
Max Boost ClockUp to 5.2 GHz
Boost TechnologyAMD Precision Boost 2
Cache
L1 Cache640 KB
L2 Cache8 MB
L3 Cache (Standard)32 MB (on-die CCD)
L3 Cache (3D V-Cache Stack)64 MB (stacked, under die)
Total L3 Cache96 MB
Total Cache (L1 + L2 + L3)104 MB
3D V-Cache Generation2nd Gen (V-Cache under die)
Power & Thermal
Default TDP120W
Max Boost TDP (PPT)162W
Max Operating Temperature (Tjmax)95°C
Recommended Cooler240–280mm Liquid Cooler (or equivalent); Cooler not included
Platform & Socket
SocketAMD AM5 (LGA 1718)
Compatible ChipsetsX870E, X870, X670E, X670, B650E, B650 (BIOS update may be required)
Min. Recommended AGESA1.2.0.1a or above
Memory
Memory TypeDDR5 Only
Memory Channels2 (Dual-Channel)
Max Memory Capacity256 GB
Memory SubtypeUDIMM
Max Memory Speed (2×1R)DDR5-5600
Max Memory Speed (2×2R)DDR5-5600
Max Memory Speed (4×1R)DDR5-3600
Max Memory Speed (4×2R)DDR5-3600
Native Memory SpeedDDR5-5600 (5600 MT/s)
ECC SupportYes (Requires motherboard support)
AMD EXPO SupportYes
PCIe & Storage
PCIe VersionPCIe 5.0
Native PCIe Lanes (Total)28
Native PCIe Lanes (Usable)24
PCIe Lane Allocationx16 GPU + x4 NVMe SSD + x4 Chipset
NVMe SupportBoot, RAID 0, RAID 1, RAID 5, RAID 10
Integrated Graphics
GPU ModelAMD Radeon™ Graphics (RDNA 2)
Graphics Core Count (CUs)2 Compute Units (128 Shaders)
GPU Frequency2200 MHz
USB Type-C DisplayPort Alt ModeYes
iGPU PurposeDisplay output / diagnostics (not for gaming)
I/O & Connectivity
Native USB 2.0 Ports (480 Mbps)1
USB Type-C DisplayPort Alt ModeYes
Overclocking & Supported Technologies
Unlocked for OverclockingYes (CPU cores, fabric & memory)
Precision Boost Overdrive (PBO)Yes
Curve OptimizerYes
AMD EXPO™ TechnologyYes
AMD Ryzen™ TechnologiesYes
AMD Ryzen Master UtilityYes
AMD-V (Virtualization)Yes
Instruction Set Extensions
Base ISAx86-64
Supported ExtensionsAES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX+, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3
Operating System Support
WindowsWindows 11 (64-bit), Windows 10 (64-bit)
LinuxRHEL x86 64-bit, Ubuntu x86 64-bit

The AMD Ryzen 7 9800X3D is an 8-core, 16-thread processor designed for Socket AM5 motherboards, running at a base frequency of 4.7 GHz and boosting up to 5.2 GHz. With 104 MB of total cache and support for DDR5 memory across two channels, this CPU handles demanding workloads and modern applications with room to spare.

Integrated AMD Radeon Graphics provide basic display output, while the 120W base TDP and 165W maximum TDP reflect its performance capability. Note that a cooling device is not included with this processor, so you will need to provide your own AM5-compatible cooler for safe operation.
