ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX) CLICK TO EXPAND
ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX)
ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX)
TieredUp Tech, Inc.

ASRock B860M X WiFi 6E Motherboard (DDR5) (Intel) (LGA1851) (TDP 125W) (M-ATX)

Motherboard● In Stock
$151.31
Qty
Flexible Payment Options
4 interest-free payments of $37.82 — Learn more
As low as $12.60/mo — Learn more
Lease-to-own from $2.90/wk — no credit needed. Apply at checkout
Finance from $6.30/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
Overview
ManufacturerASRock
ModelB860M-X WiFi 6E
Form FactorMicro ATX (mATX)
ChipsetIntel B860
PCB Layers6-Layer PCB
Part Number90-MXBRY0-A0UAYZ
CPU / Socket
SocketLGA1851
Supported CPUsIntel Core Ultra Processors (Series 2)
CPU TDP SupportUp to 125W (recommended Ultra 5 / Ultra 7)
Intel Hybrid TechnologySupported
Intel Turbo Boost Max 3.0Supported
Intel Thermal Velocity Boost (TVB)Supported
Intel Adaptive Boost Technology (ABT)Supported
Integrated NPUYes – Dedicated AI Acceleration
Power Delivery
Power Phase Design7+1+1+1+1 Power Phase
ATX Power Connector1 × 24-pin ATX
CPU Power Connectors1 × 8-pin 12V (Hi-Density) + 1 × 4-pin 12V (Hi-Density)
Memory
Memory TypeDDR5 (Non-ECC, Unbuffered)
DIMM Slots2 × DDR5 DIMM Slots
ChannelDual Channel
Max Memory SpeedUp to 9066+ MHz (OC); 6400 MHz Native (1DPC 1R)
Max Capacity128 GB
CUDIMM SupportYes – Clocked Unbuffered DIMM (CUDIMM)
XMP / EXPO SupportIntel XMP 3.0 / AMD EXPO
Tested Speeds (OC)DDR5-4400 / 6400 / 6800 / 7200 / 7600 / 7800 / 8000 / 8200 / 8400 / 9066+
Graphics Output
GPU ArchitectureIntel Xe LPG (iGPU – CPU dependent)
HDMI1 × HDMI 2.1 – supports HDR, HDCP 2.3, up to 4K @ 120Hz
DisplayPort1 × DisplayPort 1.4 with DSC – supports HDCP 2.3, up to 8K @ 60Hz / 5K @ 120Hz
Expansion Slots
PCIE1 (CPU)1 × PCIe 4.0 x16 Slot – supports x16 mode (Steel-reinforced)
PCIE2 (Chipset)1 × PCIe 4.0 x1 Slot
PCIE3 (Chipset)1 × PCIe 4.0 x4 Slot – supports x4 mode
M.2 Key E Slot1 × M.2 Key E – type 2230, WiFi/BT PCIe module / Intel CNVio2
Storage
M2_1 – Blazing M.2 (CPU)Key M – Type 2260/2280 – PCIe Gen5 x4 (128 Gb/s)
M2_2 – Hyper M.2 (Chipset)Key M – Type 2230/2242/2260/2280 – PCIe Gen4 x4 (64 Gb/s)
NVMe Boot SupportYes – Intel VMD (Volume Management Device)
SATA Ports4 × SATA3 6.0 Gb/s Connectors
USB Connectivity
USB 3.2 Gen2×2 Type-C (20 Gbps)1 × Rear (CPU)
USB 3.2 Gen1 Type-C (5 Gbps)1 × Front Header (Chipset)
USB 3.2 Gen1 Type-A (5 Gbps)5 × Total – 3 Rear + 2 Front
USB 2.0 (480 Mbps)6 × Total – 2 Rear + 4 Front
ESD ProtectionAll USB ports
USB 3.2 Gen1 Header1 × (Supports 2 USB 3.2 Gen1 ports)
USB 2.0 Headers2 × (Supports 4 USB 2.0 ports)
Front Panel Type-C Header1 × USB 3.2 Gen1 (5 Gbps)
Networking
LAN ControllerRealtek Dragon RTL8125BG
LAN Speed2.5 Gigabit (10/100/1000/2500 Mb/s)
Wi-Fi ControllerIntel AX211NGW
Wi-Fi Standard802.11axe Wi-Fi 6E – IEEE 802.11a/b/g/n/ac/ax/axe
Wi-Fi Bands2.4 GHz / 5 GHz / 6 GHz (extended band)
Wi-Fi ConfigurationDual-Band 2×2 – 2T×2R (MU-MIMO)
BluetoothBluetooth 5.3 (Low Energy, Smart Ready)
Antennas2 × ASRock WiFi 2.4/5/6 GHz External Antennas
Audio
Audio CodecRealtek ALC897
Audio Channels7.1 CH HD Audio
Audio CapacitorsNichicon Fine Gold Audiophile Capacitors
Front Panel Audio Header1 × Front Panel Audio Connector
Rear I/O Panel
Display Outputs1 × HDMI 2.1, 1 × DisplayPort 1.4
USB Type-C1 × USB 3.2 Gen2×2 Type-C (20 Gbps)
USB 3.2 Gen1 Type-A3 × USB 3.2 Gen1 (5 Gbps)
USB 2.02 × USB 2.0 Type-A
LAN Port1 × RJ-45 (2.5GBase-T)
Antenna Ports2 × SMA Antenna Connectors
Audio JacksLine Out + Microphone Input
BIOS Flashback ButtonYes – No CPU/RAM required
Onboard Headers & Connectors
CPU Fan Connectors2 × 4-pin (Smart Fan Speed Control; CPU_FAN1 up to 1A/12W)
Chassis Fan Connectors2 × 4-pin (Smart Fan Speed Control)
AIO Pump Connector1 × 4-pin (Smart Fan Speed Control)
RGB LED Header1 × 12V/G/R/B (5050 RGB strip, up to 3A/36W, max 2m)
Addressable RGB Headers2 × 5V/Data/GND (WS2812B, up to 3A/15W, max 80 LEDs, 2m)
SPI TPM Header1 ×
Power LED & Speaker Header1 ×
RGB & Lighting
RGB SoftwareASRock Polychrome SYNC / SignalRGB Compatible
RGB Header1 × Standard RGB (12V, 5050 strip)
ARGB Headers2 × Addressable RGB (5V, WS2812B)
BIOS & Software
BIOS TypeASRock Full HD UEFI / EZ Mode
BIOS FlashbackYes – Rear I/O Button (USB only, no CPU/RAM needed)
Post Status CheckerASRock Post Status Checker
Auto Driver InstallerASRock Auto Driver Installer
Tuning UtilityASRock Motherboard Utility (A-Tuning)
LAN SoftwareASRock Dragon 2.5G LAN Software
Instant FlashASRock Instant Flash
My Favorites in UEFIYes
In the Box
Accessories Included1 × I/O Shield, 2 × SATA Data Cables, 2 × ASRock WiFi 2.4/5/6 GHz Antennas, 1 × M.2 Screw, 1 × M.2 Standoff

The ASRock B860M X WiFi 6E is a Micro ATX motherboard built for Intel LGA 1851 processors, supporting up to 140W TDP and DDR5 memory at speeds up to DDR5-9066+ when overclocked. With two memory slots accommodating up to 128GB total, it provides a solid foundation for modern Intel builds in a compact form factor.

Connectivity includes built-in WiFi 6E, two M.2 slots with Gen5x4 support on the primary slot, four SATA ports, and a range of USB options including USB 3.2 Gen2x2 Type-C at the rear and both Type-A and Type-C headers for front panel expansion. Display outputs via HDMI and DisplayPort 1.4 handle integrated graphics, while one PCIe x16 slot and one PCIe x1 slot offer room for expansion cards.
