CLICK TO EXPAND
| General Information | |
|---|---|
| Product Name | AMD Wraith Stealth Stock Air CPU Cooler |
| Product Code / Model | 712-000052 (SR1) |
| Brand | AMD |
| Cooler Type | Air Cooler — Top-Down / Downdraft |
| Color | Black (Fan) / Silver (Heatsink) |
| Packaging | OEM Black Box |
| Compatibility | |
| Socket Compatibility | AMD AM4 / AM5 |
| Mounting Mechanism | Spring-loaded screw mount (uses existing motherboard backplate) |
| Compatible CPU Lines | AMD Ryzen 3, Ryzen 5, Ryzen 7 5700G (select models); bundled with 65W TDP Ryzen CPUs |
| RAM Clearance Note | Compatible with DDR4 modules without heatsink; memory depth of 45–70mm may fit but may contact cooler |
| Thermal Performance | |
| Max TDP Rating | 65W |
| Cooling Solution Type | All-aluminum extrusion; no copper heatpipes |
| Thermal Paste | Pre-applied |
| Heatsink Specifications | |
| Heatsink Design | Circular body with extruded aluminum fins |
| Heatsink Material | Aluminum |
| Contact Base Material | Aluminum |
| Heatsink Color | Silver |
| Heatsink Dimensions (L × W × H) | ~100 × 100 × 50 mm (heatsink body only) |
| Overall Dimensions (L × W × H, with fan) | ~109 × 103 × 60 mm |
| Heatsink Height (without fan) | ~46 mm |
| Profile | Low-profile / Slim |
| Heatpipes | None (direct contact aluminum extrusion) |
| Fan Specifications | |
| Fan Size | 92–96 mm (3.81–3.93 inches) |
| Fan Thickness | ~16 mm |
| Fan Speed (Min) | 1200 RPM |
| Fan Speed (Max) | 1900–2500 RPM |
| Fan Control | PWM (Pulse Width Modulation) — automatic temperature-based speed control |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Fan Color | Black |
| Number of Fans | 1 |
| Airflow | 75–100 m³/h |
| Airflow Direction | Top-down (downdraft) |
| Acoustics | |
| Noise Level | ~22–28.5 dB(A) (low noise) |
| Noise Rating | Near-silent operation at low load; ramps up under thermal stress |
| Electrical & Connector | |
| Power Connector | 4-Pin PWM |
| Cable Length (approx.) | ~9 inches (~23 cm) |
| Motherboard Header | CPU_FAN (4-pin PWM) |
| Lighting & Aesthetics | |
| RGB / LED Lighting | None |
| AMD Logo | Present on fan hub/shroud (non-illuminated) |
| Bundled CPU Models (Examples) | |
| Ryzen 3 Series | Ryzen 3 8300G and select Ryzen 3 models |
| Ryzen 5 Series | Ryzen 5 1400, 5600G, 7500F, 8400F, 8500G, 8600G, 9500F, 9600 and select others |
| Ryzen 7 Series | Ryzen 7 5700G, 8700F (select models with 65W TDP) |
| Additional Details | |
| OEM / Retail | OEM (revision numbers may vary) |
| Supplied Manufacturers | Cooler Master, Foxconn, Delta Electronics (varies by revision) |
| VRM Cooling | Yes — top-down airflow assists VRM and socket area cooling |
| Overclocking Support | Not recommended; designed for stock operation at 65W TDP |
