Gigabyte NVIDIA GeForce RTX 5060 Windforce OC 8GB GDDR7 3-Fan Graphics Card (199mm) (TDP 160W) (Black) CLICK TO EXPAND
0.17583900 177392576749425622
Gigabyte NVIDIA GeForce RTX 5060 Windforce OC 8GB GDDR7 3-Fan Graphics Card (199mm) (TDP 160W) (Black)
Geek Tech Supply

Gigabyte NVIDIA GeForce RTX 5060 Windforce OC 8GB GDDR7 3-Fan Graphics Card (199mm) (TDP 160W) (Black)

Graphics Card● Out of Stock
$395.99
Qty
Flexible Payment Options
4 interest-free payments of $98.99 — Learn more
As low as $32.99/mo — Learn more
Lease-to-own from $7.61/wk — no credit needed. Apply at checkout
Finance from $16.49/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
General
ModelGeForce RTX™ 5060 EAGLE MAX OC 8G
Part NumberGV-N5060EAGLEMAX OC-8GD
ColorBlack
SeriesGeForce RTX 50 Series
Release DateMay 19, 2025
GPU
Graphics ProcessorGeForce RTX™ 5060
GPU DieGB206-250 (GB206)
ArchitectureNVIDIA Blackwell
Fabrication Process4 nm (TSMC N4P)
Die Size181 mm²
Transistors21.9 Billion
Transistor Density121M / mm²
Processor Cores
CUDA® Cores3840
Tensor Cores120
Ray Tracing Cores30
Streaming Multiprocessors (SM)30
TMUs120
ROPs48
Clock Speeds
Base Clock2280 MHz
Boost Clock (OC Mode)2550 MHz
Reference Boost Clock2497 MHz
Memory
Memory Size8 GB (8192 MB)
Memory TypeGDDR7
Memory Bus Width128-bit
Memory Clock (Effective)28 Gbps (3500 MHz)
Memory Bandwidth448.0 GB/s
Display & Connectivity
DisplayPort Outputs3× DisplayPort 2.1b
HDMI Output1× HDMI 2.1b
Max Digital Resolution7680 × 4320 (8K)
Multi-Monitor SupportUp to 4 displays
InterfacePCI-Express 5.0 x8
API Support
DirectXDirectX 12 API
OpenGLOpenGL 4.6
CUDAYes
DLSSDLSS 4 (Multi Frame Generation)
Ray TracingFull hardware ray tracing with neural rendering
NVIDIA ReflexNVIDIA Reflex 2 with Frame Warp
Cooling System
Cooling SolutionWINDFORCE Cooling System
Fan Count3 Fans
Fan TypeHawk Fan (Eagle wing-inspired blade design)
Fan BearingGraphene nano lubricant sleeve bearing (2.1× lifespan extension)
Semi-Passive ModeYes — 3D Active Fan (fans stop at low load)
Heat PipesAdvanced composite copper heat pipes
Thermal Interface MaterialServer-grade thermal conductive gel (VRAM & MOSFETs)
Airflow ImprovementUp to 53.6% increase in air pressure; 12.5% increase in air volume
Power
TDP160W
Power Connector1× 8-Pin
Recommended PSU550W
Form Factor & Dimensions
PCB FormATX
Card Length281 mm
Card Width115 mm
Card Height40 mm
Slot Requirement2-Slot
Design & Features
BackplateVentilated metal backplate
Reinforced StructureYes
PCB ManufacturingFully automated production (no sharp solder protrusions)
RGB LightingNo
Dual BIOSNo
Software
Control SoftwareGIGABYTE Control Center (GCC)
OS SupportWindows 10 64-bit, Windows 11 64-bit
NVIDIA BroadcastYes (9th-gen NVIDIA Encoder)
NVIDIA StudioYes
NVIDIA ACEYes
In the Box
AccessoriesQuick Guide
The Gigabyte NVIDIA GeForce RTX 5060 Eagle Max OC 8GB GDDR7 3-Fan Graphics Card (281mm) (TDP 160W) (Black) is a Common-tier custom gaming PC built and tested by TieredUp Tech in Orange, TX. This machine delivers 100+ FPS in esports titles like Fortnite, Valorant, and Apex Legends at 1080p ultra settings — making it the perfect entry point into PC gaming. The RTX 5060 Eagle Max OC 8GB GDDR7 3 GPU handles everything from fast-paced competitive shooters to visually demanding open-world titles. With 8GB of RAM, you have plenty of headroom for gaming, streaming, and running background applications simultaneously. This build is optimized for Fortnite, Valorant, Apex Legends, Minecraft, League of Legends, and CS2. Whether you are jumping into your first PC gaming experience or upgrading from an older system, the Gigabyte NVIDIA GeForce RTX 5060 Eagle Max OC 8GB GDDR7 3-Fan Graphics Card (281mm) (TDP 160W) (Black) delivers exceptional performance straight out of the box. Every Common-tier BitCrate gaming PC is hand-assembled, stress-tested, and quality checked by our technicians before shipping. We stand behind every build with a 30-day warranty and ongoing technical support from our team in Orange, TX. Priced at $395.99 and in stock now, the Gigabyte NVIDIA GeForce RTX 5060 Eagle Max OC 8GB GDDR7 3-Fan Graphics Card (281mm) (TDP 160W) (Black) represents outstanding value for its performance tier. Order today and experience the TieredUp Tech difference — premium gaming performance at every price point. Specifications at a glance: • Graphics: RTX 5060 Eagle Max OC 8GB GDDR7 3 • Memory: 8GB • Build Tier: Common • Built & tested in Orange, TX • 30-day warranty included • Free shipping on orders over $1,200
