ASRock B850M Pro-A WiFi 6E Motherboard (DDR5) (AM5) (TDP 110W) (M-ATX)

Motherboard● In Stock
$143.98
Qty
Flexible Payment Options
4 interest-free payments of $35.99 — Learn more
As low as $11.99/mo — Learn more
Lease-to-own from $2.76/wk — no credit needed. Apply at checkout
Finance from $5.99/mo — instant decisions. Learn more
🛡️30-Day Warranty
🚚Free Ship $1,200+
🔧Expert Support
Overview
ModelASRock B850M Pro-A WiFi
Form FactorMicro ATX (mATX)
Dimensions244 mm × 244 mm
ChipsetAMD B850
PCB Layers6-Layer PCB
Part Numbers90-MXBR9-A0UAYZ / 90-MXBR90-A0UAYZ
Processor
SocketAMD AM5 (LGA1718)
Compatible CPUsAMD Ryzen™ 9000, 8000 (Phoenix 1 & 2), and 7000 Series
CPU TDP SupportUp to 110W
Integrated GraphicsAMD RDNA™ (CPU-dependent)
Power Delivery
Power Phase Design8+2+1 Phase (VCore + SOC + MISC)
MOSFET TypeDr.MOS
ATX Power Connector1 × 24-pin ATX
CPU Power Connector1 × 8-pin ATX 12V (Hi-Density)
Memory
Memory TypeDDR5 (ECC / non-ECC, Unbuffered)
DIMM Slots4 × DDR5 DIMM
ChannelDual Channel
Max SpeedDDR5-4400 up to DDR5-8000+ (OC)
Max Capacity256 GB
OC ProfilesAMD EXPO™ & Intel XMP
Expansion Slots
PCIE1 (CPU)1 × PCIe 5.0 x16 (x16 mode; Gen4x8 w/ Ryzen 8000 P1; Gen4x4 w/ Ryzen 8000 P2); 15μ Gold Contact
PCIE2 (Chipset)1 × PCIe 4.0 x4 (x4 mode; disabled if M2_3 occupied)
Key E Slot (Chipset)1 × M.2 Key E, type 2230 (Wi-Fi / BT PCIe module — pre-installed)
Storage
M2_1 — Blazing M.2 (CPU)Key M, type 2280, PCIe Gen5×4 (128 Gb/s); Gen4×4 w/ Ryzen 8000 P1; Gen4×2 w/ Ryzen 8000 P2
M2_2 — Hyper M.2 (Chipset)Key M, type 2280, PCIe Gen4×4 (64 Gb/s)
M2_3 — Hyper M.2 (CPU)Key M, type 2280, PCIe Gen4×4 (64 Gb/s); shares bandwidth with PCIE2
SATA Ports4 × SATA3 6.0 Gb/s
RAID SupportRAID 0, 1, 10 for SATA; RAID 0, 1, 10 for M.2 NVMe
NVMe BootSupported on all M.2 sockets
Display Outputs
HDMI1 × HDMI 2.1 (TMDS/FRL 8G Compatible), supports HDR, HDCP 2.3, up to 4K @ 120Hz
DisplayPort1 × DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3
GPU RequiredRequires CPU with integrated AMD RDNA™ graphics
USB — Rear I/O
USB 3.2 Gen2 Type-C (10 Gb/s)1 × (CPU)
USB 3.2 Gen2 Type-A (10 Gb/s)1 × (CPU)
USB 3.2 Gen1 Type-A (5 Gb/s)2 × (Chipset)
USB 2.0 Type-A (480 Mb/s)4 × (via GL852 Hub, Chipset)
USB — Front Panel Headers
USB 3.2 Gen1 Type-C Header (5 Gb/s)1 × (Chipset)
USB 3.2 Gen1 Headers (5 Gb/s)2 × headers (supports 4 × USB 3.2 Gen1 ports)
USB 2.0 Headers (480 Mb/s)2 × headers (supports 4 × USB 2.0 ports)
Networking
LAN ControllerRealtek RTL8125BG Dragon 2.5G
LAN Speed2.5 Gb/s
Wi-Fi Standard802.11axe Wi-Fi 6E (IEEE 802.11a/b/g/n/ac/ax/axe)
Wi-Fi Bands2.4 GHz / 5 GHz / 6 GHz
Wi-Fi ConfigurationDual-band 2×2 MU-MIMO; 2T×2R diversity
Antennas2 × ASRock Wi-Fi 2.4/5/6 GHz antennas (included)
BluetoothBluetooth 5.2
Wi-Fi 6E OS RequirementWindows 11 required for 6 GHz band
Audio
Audio CodecRealtek ALC897
Channels7.1 CH HD Audio
Front Audio Header1 × HD Audio (HD_AUDIO1)
Fan & Cooling Headers
CPU Fan Headers2 × 4-pin (Smart Fan Speed Control); CPU_FAN1 up to 1A/12W
Chassis Fan Headers3 × 4-pin (Smart Fan Speed Control); up to 3A/36W each
AIO Pump Header1 × 4-pin (Smart Fan Speed Control); up to 3A/36W
Fan ControlPWM & DC auto-detect (CPU_FAN2, CHA_FAN1–3, AIO_PUMP)
RGB / Lighting
RGB LED Header1 × 4-pin (12V/G/R/B), max 3A/12W, up to 36W — for standard 5050 RGB LED strip
Addressable RGB Headers2 × 3-pin ARGB (5V/Data/GND), WS2812B, max 3A/5V (15W), up to 80 LEDs per strip
RGB SoftwareASRock Polychrome SYNC; SignalRGB compatible
Onboard Headers & Connectors
SPI TPM Header1 ×
Power LED & Speaker Header1 ×
Front Panel Header1 × (Power button, Reset button, HDD LED, Power LED)
Post Status Checker LEDsYes (CPU, DRAM, VGA, BOOT indicators)
CLRCMOS Jumper1 × (CLRCMOS1)
BIOS
BIOS TypeAMI UEFI (128 Mb SPI Flash ROM)
BIOS FeaturesASRock EZ Mode, Full HD UEFI, Instant Flash
BIOS FlashbackYes — via dedicated button; no CPU or RAM required
Super I/ONCT6796D-S
Software & Utilities
Tuning UtilityASRock A-Tuning (Fan-Tastic Tuning)
Network SoftwareASRock Dragon 2.5G LAN Software
RGB ControlASRock Polychrome SYNC; SignalRGB
Driver InstallerASRock Auto Driver Installer (pre-loaded LAN driver)
Update ToolASRock Live Update & APP Shop
Box Contents
Included Accessories2 × SATA data cables; 2 × Wi-Fi antennas; M.2 screws & standoffs; Quick installation guide
The ASRock B850M Pro-A WiFi 6E Motherboard (DDR5) (AM5) (TDP 110W) (M-ATX) is a Common-tier custom gaming PC built and tested by TieredUp Tech in Orange, TX. This machine delivers 100+ FPS in esports titles like Fortnite, Valorant, and Apex Legends at 1080p ultra settings — making it the perfect entry point into PC gaming. This build is optimized for Fortnite, Valorant, Apex Legends, Minecraft, League of Legends, and CS2. Whether you are jumping into your first PC gaming experience or upgrading from an older system, the ASRock B850M Pro-A WiFi 6E Motherboard (DDR5) (AM5) (TDP 110W) (M-ATX) delivers exceptional performance straight out of the box. Every Common-tier BitCrate gaming PC is hand-assembled, stress-tested, and quality checked by our technicians before shipping. We stand behind every build with a 30-day warranty and ongoing technical support from our team in Orange, TX. Priced at $143.98 and in stock now, the ASRock B850M Pro-A WiFi 6E Motherboard (DDR5) (AM5) (TDP 110W) (M-ATX) represents outstanding value for its performance tier. Order today and experience the TieredUp Tech difference — premium gaming performance at every price point. Specifications at a glance: • Build Tier: Common • Built & tested in Orange, TX • 30-day warranty included • Free shipping on orders over $1,200
